11/30/04
A uRA Valve
Model ND05
Operating Instructions
By AME 470 Ltd.
Team Unum

LCD
Smarthead™
(−) Button
(+) button
Enter Button
Kill Button
AC Jack
Inlet Fitting
WARNING “READ ALL INSTRUCTIONS” Failure to follow the recommended operating procedures may result in serious personal injury.
Operating Instructions
-
Insert the AC adapter into the AC jack on the bottom of the AuRA Valve; Plug the AC adapter into a standard wall socket. This will activate the AuRA Valve.
-
If inflating an automobile or bicycle tire, firmly insert the tire stem into the Smarthead™. Lift the Smarthead™ lever to lock the Smarthead™ onto the tire stem. If inflating an athletic ball, firmly insert the inflation needle into the Smarthead™. Lift the Smarthead™ lever to lock the Smarthead™ onto the needle. Insert the needle into the inflation valve on the ball.
-
Connect the inlet fitting to any existing hand or foot pump hose.
-
Press the Enter button to begin pressure selection.
-
Use the (−) & (+) buttons to select the desired vessel pressure. Press Enter when the desired target pressure is displayed. AuRA Valve will begin the inflation process. Do not input a pressure beyond the capacity of the inflatable.
-
Begin inflating the vessel using the hand, foot, or automatic pump. The AuRA Valve will automatically stop inflation upon reaching the target pressure.
-
Inflation may be immediately terminated at any time by pressing the Kill button.
-
When inflation is completed, unplug the AuRA Valve to power down the system. Enjoy your AuRA Valve.
